Control System & PLC — What This Subject Is About
To provide a solid understanding of control system principles — open-loop and closed-loop systems, feedback and stability analysis — to model and analyse control systems, apply PID control, and implement PLC programming (Ladder Logic, Function Block Diagram) for industrial automation, with hands-on experience in designing, implementing and troubleshooting PLC-based systems.
Subject 5.2.1 — Program Elective-1, Option 1 (Theory) • Total 100 Marks • 3 Credits • L 3 – P 0 • Choose this OR Microwave and Radar OR Digital Communication Systems • 5th Semester — Electronics Engineering • Session 2026–27
Note: Unit 1 in the PDF prints “Close App Control System” (sic); it is reproduced exactly as printed.
What You Will Study
Unit 1 — Introduction to Control System (9 Periods, 21%)
Open loop Control System and Close App Control System - block diagram and its elements, properties and application (with example) and Comparison between open and close loop Control System, Block diagram of feedback Control System and its elements, Definition and Explanation of the following Control System - Linear and Non-linear System, Continuous and Discrete System, Static and dynamic System
Open-loop vs closed-loop control, feedback, and the basic types of control systems — linear/non-linear, continuous/discrete, static/dynamic.
Unit 2 — Transfer Function (6 Periods, 14%)
Definition of Transfer function and its use in Control System, Transfer function of the following: Open loop and Close Loop System, Simple RC low pass and High pass filter, Characteristic Equation, Pole-Zero Concept of Transfer Function, Initial value and final value theorem.
The transfer function: a mathematical model of a system, its poles and zeros, and the initial- and final-value theorems.
Unit 3 — Time Domain Analysis and Stability Theory (10 Periods, 24%)
Time response of first order system with unit step input, Time response of second order system with unit step input, Basic idea of delay time, rise time, setting time, steady state error, max overshoot, damping ratio (No Derivation), Over damped, under damped, critically damped, un damped system (basic idea only) and Pole-zero representation, Nature of transit response, Damping ratio (No Derivation), Basic concept of stability analysis by Routh-Hurwitz Criterion
How a system responds over time to a step input — rise time, overshoot, damping — and the Routh-Hurwitz test for whether it is stable.
Unit 4 — Basic Controllers (7 Periods, 17%)
Introduction to controllers, need of controller, Type of controller (Basic idea and Mathematical expression only): (a) On-off controller b) Proportional controller c) PD controller d) PI controller e) PID controller
The controllers that keep a system on target: on-off, proportional, PD, PI and the workhorse PID controller.
Unit 5 — Introduction to PLC and Instruction Set (10 Periods, 24%)
Concept of PLC, building block of PLC, function of various blocks, limitation of relays, advantage of PLC over electromagnetic relays, different programming languages, PLC manufacturer, working of PLC, basic operation and principles of PLC, architectural details. Basic instructions like latch, master control self-holding relays, timer instruction like retentive timers, resetting of timers, counter instructions like up counter, resetting of counters.
The programmable logic controller: its blocks, why it replaced relay panels, its programming languages, and its basic instructions — latches, timers and counters.
Complete Syllabus
The full examination scheme, the complete practicals list and the reference books from the official syllabus. The unit-wise topics are in the "What You Will Study" section above.
Examination Scheme
| Code | Paper | Type | L – P | Credits | Internal | External | Total |
|---|---|---|---|---|---|---|---|
| 5.2.1 | Program Elective-1: Control System & PLC | Theory | 3 – 0 | 3 | Theory 40 | Theory 60 (3 hrs) | 100 |
| Control System & PLC Total | 3 | 40 | 60 | 100 | |||
Units at a Glance
| Unit | Topic | Periods | Marks Share |
|---|---|---|---|
| 1 | Introduction to Control System | 9 | 21% |
| 2 | Transfer Function | 6 | 14% |
| 3 | Time Domain Analysis and Stability Theory | 10 | 24% |
| 4 | Basic Controllers | 7 | 17% |
| 5 | Introduction to PLC and Instruction Set | 10 | 24% |
Reference Books
As listed in the syllabus:
- Modern Control Engineering, K. Ogata, PHI Publications.
- Control System Engineering I.J. Nagrath and M. Gopal, New Age International Publishers.
- Linear Control Systems, B.S. Manke, Khanna Publishers.
- Introduction to PLCs, Gary Dunning, Tata McGraw Hill.
- Control System (With MATLAB Programs), Sonveer Singh and Sanjay Agrwal, I. K. International
Frequently Asked Questions
How many marks is Control System & PLC worth in the 5th semester?
Program Elective-1: Control System & PLC (5.2.1) is 100 marks. Total: 100 marks, 3 credits. The full scheme table is in the Complete Syllabus section above.
Which units carry the most weightage in Control System & PLC?
Time Domain Analysis and Stability Theory and Introduction to PLC and Instruction Set, 24% each. The full unit-wise weightage table is in the Complete Syllabus section above.
Which books should I refer to for Control System & PLC?
The syllabus lists Modern Control Engineering, K. Ogata, PHI Publications., and Control System Engineering I.J. Nagrath and M. Gopal, New Age International Publishers., among others. The full list is in the Complete Syllabus section above.
Is Control System & PLC a theory subject or a practical subject?
It is assessed as theory — see the examination scheme in the Complete Syllabus section above.
How can I download the Control System & PLC syllabus PDF?
The PDF is free to download — use the download link in the Download section below. It is prepared by KAMALDNP Academy from the official BTEUP syllabus.
Related Syllabus Posts
- BTEUP Electronics 5th Semester Syllabus 2026-27
- BTEUP Electronics Complete Syllabus 2026-27 — 3rd, 4th, 5th & 6th Semester (All Subjects)
- Optical Fiber Communication — BTEUP Electronics 5th Semester Syllabus 2026-27
- Microwave and Radar — BTEUP Electronics 5th Semester Syllabus 2026-27
- Digital Communication Systems — BTEUP Electronics 5th Semester Syllabus 2026-27
Download the Control System & PLC Syllabus PDF
Download the complete Control System & PLC syllabus PDF below — prepared by KAMALDNP Academy, with the full topic list, practicals and reference books.
Download the Control System & PLC Syllabus PDF
Source: BTEUP 3rd Year curriculum (folder2627), approved in C.D.C. meeting held on 16.07.2026. Topic lists follow the official syllabus; short explanations are the author's own plain-English summaries, not syllabus text. Please confirm with your own polytechnic for any local changes.
